US Digital E6 Optical Encoder
MFR US DigitalMODEL E6-5000
Cost-effective optical encoder with 5000 CPR and quadrature output. Features easy mounting, differential line driver, and excellent value for hobby and educational robotics.
Specifications
Specifications· 10 fields
- Resolution
- 5000 CPR
- Counts
- 20,000 with 4x
- Max Speed
- 15,000 RPM
- Output
- Differential RS422
- Channels
- A, B, Index
- Shaft Diameter
- 0.25 inch (6.35mm)
- Operating Voltage
- 5V DC
- Operating Temp
- -10°C to 70°C
- Dimensions
- Ø38 x 32 mm
- Weight
- 40g
