Oriental Motor NEMA34 Stepper Motor
MFR Oriental Motor USAMODEL PK596AW
High-torque NEMA34 stepper motor for precision robotic positioning. Features low vibration, high accuracy, and robust construction for industrial use.
Specifications
Specifications· 13 fields
- Step Angle
- 1.8°
- Holding Torque
- 4.2 N⋅m
- Current
- 3.0 A
- Resistance
- 1.4 Ω
- Inductance
- 8.5 mH
- Inertia
- 1200 g⋅cm²
- Steps
- 200 steps/rev
- Voltage
- 24-48 VDC
- Frame Size
- NEMA34 (86mm)
- Length
- 80 mm
- Shaft
- 12.7 mm diameter
- Weight
- 2.1 kg
- Protection
- IP40
