Progressive Automations PA-17 Precision Actuator
MFR Progressive AutomationsMODEL PA-17
Compact precision linear actuator with 6-inch stroke and 330 lbs force. Features hall effect sensors, low noise operation, and excellent position accuracy for robotic applications.
Specifications
Specifications· 10 fields
- Max Force
- 330 lbs (1468 N)
- Stroke Length
- 2-16 inches
- Speed
- 0.39-1.57 inches/sec
- Voltage
- 12V DC
- Sensors
- Hall effect position
- Duty cycle
- 20% at max load
- Noise
- <45 dB
- Protection
- IP54
- Backlash
- 0.1mm
- Weight
- 0.8 kg
