Maxon EC 90 flat Brushless Motor 90W
MFR maxon motorMODEL EC 90 flat
Premium brushless DC motor with exceptional power density. Features ironless rotor, long service life, and precise control for medical robotics, aerospace, and high-performance automation.
Specifications
Specifications· 10 fields
- Nominal Voltage
- 24V
- Nominal Power
- 90W
- Stall Torque
- 204 mNm
- No Load Speed
- 6630 RPM
- Efficiency
- 90%
- Motor Constant
- 39.1 mNm/√W
- Rotor Inertia
- 235 gcm²
- Weight
- 465g
- Diameter
- 90 mm
- Encoder Option
- 3-channel Hall sensors
