MaxBotix MB7389 HRXL-MaxSonar-WRS
MFR MaxBotixMODEL MB7389
High-resolution ultrasonic sensor with 10m range and weather resistance. Features narrow beam pattern, serial/analog/PWM outputs, and excellent outdoor performance for mobile robots.
Specifications
Specifications· 10 fields
- Range
- 0.3-10m
- Resolution
- 1mm
- Beam Width
- 5°
- Frequency
- 42 kHz
- Reading Rate
- 10 Hz
- Outputs
- Serial, Analog, PWM
- Operating Voltage
- 3.3-5V
- Weather Resistant
- Yes
- Operating Temp
- -40°C to 65°C
- Dimensions
- 31.8 x 63.5 mm
