Systems · Robotic Arms
KUKA LBR iisy 11 kg
MFR KUKAMODEL LBR iisy 11 R1300
Collaborative robot with 11 kg payload and 1300 mm reach. Features sensitive robotics technology with integrated torque sensors in all joints for safe human-robot collaboration.
Specifications
Specifications· 12 fields
- Payload
- 11 kg
- Reach
- 1300 mm
- Repeatability
- ±0.1 mm
- Degrees of freedom
- 7
- Mounting
- Floor, ceiling, wall, angle
- Power consumption
- < 1000 W
- Weight
- 29 kg
- Operating temperature
- +5°C to +45°C
- Protection class
- IP54
- Collaborative
- Yes
- Max tcp speed
- 2.0 m/s
- Certification
- CE, ISO 10218, ISO/TS 15066
