Components · Sensors
VectorNav VN-100 IMU/AHRS
MFR VectorNav TechnologiesMODEL VN-100T-CR
Miniature high-performance IMU/AHRS with onboard processing. Provides accurate orientation data for robotics, UAVs, and autonomous systems.
Specifications
Specifications· 13 fields
- Gyro Range
- ±2000 °/s
- Accel Range
- ±16 g
- Mag Range
- ±2.5 gauss
- Gyro Noise
- 0.0035 °/s/√Hz
- Accel Noise
- 100 µg/√Hz
- Output Rate
- 800 Hz
- Latency
- 2 ms
- Interface
- UART, SPI, I2C
- Supply
- 3.2-5.5 VDC
- Current
- 67 mA typical
- Operating Temp
- -40°C to +85°C
- Dimensions
- 24 x 22 x 3 mm
- Weight
- 1 g
