igus drylin N-10-40 Linear Bearing
MFR igusMODEL drylin N-10-40
Self-lubricating polymer linear bearing with 10mm shaft diameter. Features maintenance-free operation, corrosion resistance, and silent running for cost-effective linear motion.
Specifications
Specifications· 10 fields
- Shaft Diameter
- 10 mm
- Length
- 40 mm
- Dynamic Load
- 80 N
- Static Load
- 160 N
- Material
- iglidur J polymer
- Max Speed
- 5 m/s
- Max Accel
- 50 m/s²
- Operating Temp
- -40°C to 90°C
- Lubrication
- Self-lubricating
- Weight
- 8g
