Avago AEDR-8300 Optical Encoder
MFR BroadcomMODEL AEDR-8300-102
High-resolution optical rotary encoder for precise position feedback. Features quadrature output and index pulse.
Specifications
Specifications· 9 fields
- Resolution
- 102 CPR
- Quadrature Output
- 408 counts/rev
- Max Speed
- 6000 rpm
- Voltage
- 5 V
- Current
- 40 mA
- Output Type
- TTL compatible
- Operating Temp
- -40°C to +100°C
- Shaft Diameter
- 6 mm
- Weight
- 50 g
