Hengstler AC61 Absolute Encoder
MFR Hengstler GmbHMODEL AC61/1213EK.72SPB
High-precision absolute rotary encoder with CANopen interface. Single-turn and multi-turn versions available for precise position feedback in robotics.
Specifications
Specifications· 13 fields
- Resolution
- 13-bit single-turn
- Accuracy
- ±0.1°
- Interface
- CANopen
- Shaft Diameter
- 10 mm
- Flange Size
- 58 mm
- Max Speed
- 12000 rpm
- Supply
- 10-30 VDC
- Current
- 80 mA max
- Protection
- IP67
- Operating Temp
- -40°C to +100°C
- Vibration
- 55 Hz, 2g
- Shock
- 500g, 1ms
- Cable
- 2m, 5-pin M12 connector
