Bosch BMI088 High-Performance IMU Module
MFR Bosch SensortecMODEL BMI088
Automotive-grade 6-axis IMU with separated gyroscope and accelerometer. Features low noise, high stability, and excellent temperature performance for precise motion tracking.
Specifications
Specifications· 10 fields
- Dof
- 6 (3-axis gyro + accel)
- Gyro Range
- ±125 to ±2000 deg/s
- Accel Range
- ±3g to ±24g
- Output Rate
- 2 kHz gyro, 1.6 kHz accel
- Gyro Noise
- 0.014 deg/s/√Hz
- Accel Noise
- 175 µg/√Hz
- Interface
- SPI, I2C
- Operating Voltage
- 2.4-3.6V
- Dimensions
- 3.0 x 4.5 x 0.95 mm
- Automotive
- AEC-Q100 qualified
