Components · Sensors
ATI Industrial Automation Axia80 F/T Sensor
MFR ATI Industrial AutomationMODEL Axia80-M20
Precision 6-axis force/torque sensor with 80N force and 20Nm torque capacity. Features silicon strain gauge technology, high resolution, and industry-leading accuracy for assembly and testing.
Specifications
Specifications· 10 fields
- Axes
- 6 (Fx, Fy, Fz, Tx, Ty, Tz)
- Force Range
- ±80N (Fx, Fy), ±240N (Fz)
- Torque Range
- ±20Nm
- Resolution
- 1/80 N, 1/800 Nm
- Accuracy
- 0.25% of full scale
- Sample Rate
- 7000 Hz
- Interface
- Ethernet, EtherCAT, DeviceNet
- Overload Capacity
- 300% in all axes
- Weight
- 1.2 kg
- Mounting
- M20 x 1.5 thread
