Xsens MTi-680G GNSS/INS
MFR Movella (Xsens)MODEL MTi-680GDEFENCE-ADJACENT
Industrial-grade GNSS/INS system with RTK support. Combines 9-DOF IMU with dual-antenna GNSS for centimeter-level positioning. Ideal for autonomous vehicles, UAVs, and mobile robotics.
We have no supplier for this
Movella (Xsens) makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Specifications· 10 fields
- Dof
- 9 (3-axis gyro, accel, mag)
- Weight
- 125g
- Antennas
- Dual for heading
- Gyro Range
- ±2000 deg/s
- Interface
- RS232, USB, CAN
- Accel Range
- ±16g
- Output Rate
- 100 Hz IMU, 20 Hz GNSS
- Rtk Accuracy
- 1cm + 1ppm horizontal
- Gnss Channels
- 184
- Operating Temp
- -40°C to 85°C
