Components · Sensors
VectorNav VN-300 Dual Antenna GPS/INS
High-performance GPS-aided INS with dual GNSS antennas. Features advanced sensor fusion, MEMS IMU, and precise heading determination for demanding robotic navigation applications.
We have no supplier for this
VectorNav Technologies makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Unit price
$5,995.00
Confirmed before you pay
Priced from live catalog
Seller of record listed
Specifications· 10 fields
- Weight
- 65g
- IMU Type
- MEMS
- Gyro Range
- ±2000 deg/s
- Interface
- UART, SPI, USB
- Accel Range
- ±16g
- Dimensions
- 58 x 58 x 14 mm
- Output Rate
- 800 Hz
- Gnss Receivers
- Dual
- Heading Accuracy
- 0.3° RMS
- Position Accuracy
- 2.5m CEP
