Thomson Electrak HD Linear Actuator
MFR Thomson LinearMODEL Electrak HDDEFENCE-ADJACENT
Heavy-duty electric linear actuator with 10,000 lbs (44.5 kN) force capacity and 24-inch stroke. Features IP66 rating, integrated limit switches, and rugged construction for industrial robotics.
We have no supplier for this
Thomson Linear makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Specifications· 10 fields
- Speed
- 0.5-2 inches/sec
- Voltage
- 12V or 24V DC
- Backlash
- <0.5mm
- Max Force
- 10,000 lbs (44.5 kN)
- Mounting
- Clevis both ends
- Duty cycle
- 25% at max load
- Protection
- IP66
- Stroke Length
- 2-24 inches (50-610mm)
- Limit Switches
- Integrated
- Operating Temp
- -26°C to 65°C
