THK SRS15M Linear Guide Rail
MFR THKMODEL SRS15M
Miniature linear guide rail with 15mm width and high load capacity. Features 4-direction equal load rating, high rigidity, and smooth operation for precision linear motion systems.
We have no supplier for this
THK makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Specifications· 10 fields
- Preload
- Medium
- Accuracy
- Normal grade
- Material
- Steel
- Rail Width
- 15 mm
- Block Width
- 28 mm
- Rail Length
- 500 mm
- Static Load
- 8.73 kN
- Block Length
- 34.7 mm
- Dynamic Load
- 5.44 kN
- Moment Capacity
- 54 Nm (My, Mz)
