Oriental Motor NEMA34 Stepper Motor
MFR Oriental Motor USAMODEL PK596AW
High-torque NEMA34 stepper motor for precision robotic positioning. Features low vibration, high accuracy, and robust construction for industrial use.
We have no supplier for this
Oriental Motor USA makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Specifications· 13 fields
- Shaft
- 12.7 mm diameter
- Steps
- 200 steps/rev
- Length
- 80 mm
- Weight
- 2.1 kg
- Current
- 3.0 A
- Inertia
- 1200 g⋅cm²
- Voltage
- 24-48 VDC
- Frame Size
- NEMA34 (86mm)
- Step Angle
- 1.8°
- Inductance
- 8.5 mH
- Protection
- IP40
- Resistance
- 1.4 Ω
- Holding Torque
- 4.2 N⋅m
