Pilz PNOZ X3 Safety Relay
MFR PilzMODEL PNOZ X3 24VAC 24VDC
Safety relay for monitoring emergency stop circuits, safety gates, light barriers and pressure-sensitive mats. Meets highest safety standards for industrial automation.
We have no supplier for this
Pilz makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Specifications· 12 fields
- Reset
- Manual/automatic selectable
- Weight
- 130 g
- Dimensions
- 22.5 x 99 x 114.5 mm
- Protection
- IP40
- Connections
- Screw terminals
- Response time
- ≤ 15 ms
- Certifications
- TÜV, BG, UL, CSA
- Supply voltage
- 24 V AC/DC
- Safety category
- Category 4 to EN ISO 13849-1
- Safety integrity
- SIL 3 to IEC 61508
- Switching capacity
- 6 A at 250 V AC
- Operating temperature
- -25°C to +60°C
