Maxon EC 90 flat Brushless Motor 90W
MFR maxon motorMODEL EC 90 flat
Premium brushless DC motor with exceptional power density. Features ironless rotor, long service life, and precise control for medical robotics, aerospace, and high-performance automation.
We have no supplier for this
maxon motor makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Unit price
$1,295.00
Confirmed before you pay
Priced from live catalog
Seller of record listed
Specifications· 10 fields
- Weight
- 465g
- Diameter
- 90 mm
- Efficiency
- 90%
- No Load Speed
- 6630 RPM
- Stall Torque
- 204 mNm
- Nominal Power
- 90W
- Rotor Inertia
- 235 gcm²
- Encoder Option
- 3-channel Hall sensors
- Motor Constant
- 39.1 mNm/√W
- Nominal Voltage
- 24V
