Kollmorgen TBM Frameless Torque Motor 60mm
MFR KollmorgenMODEL TBM-6012
High-torque frameless brushless motor for direct-drive applications. Features zero cogging, high torque density, and compact design for robotic joints, gimbals, and precision positioning.
We have no supplier for this
Kollmorgen makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Unit price
$2,895.00
Confirmed before you pay
Priced from live catalog
Seller of record listed
Specifications· 10 fields
- Weight
- 310g
- Back EMF
- 35.5 V/kRPM
- Cogging
- <1% of peak torque
- Peak Torque
- 1.8 Nm
- Stack Length
- 38 mm
- Inner Diameter
- 32 mm
- Outer Diameter
- 60 mm
- Torque Constant
- 0.35 Nm/A
- Continuous Torque
- 0.6 Nm
- Thermal Resistance
- 2.8°C/W
