Components · Servo Drives
FANUC α-i Series Servo Amplifier
MFR FANUCMODEL A06B-6240-H209
High-performance servo amplifier with advanced control algorithms and built-in safety functions. Features regenerative power supply and optimized motor control.
We have no supplier for this
FANUC makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Unit price
$2,899.00
Confirmed before you pay
Priced from live catalog
Seller of record listed
Specifications· 11 fields
- Weight
- 3.2 kg
- Feedback
- Absolute encoder compatible
- Dimensions
- 80 x 340 x 260 mm
- Protection
- IP20
- Communication
- FSSB (Fiber optic)
- Input voltage
- 3-phase 200-230V AC
- Control method
- PWM control
- Output current
- 40 A (continuous)
- Safety functions
- STO, SS1, SS2
- Continuous output
- 9 kW
- Operating temperature
- 0°C to +55°C
