Motor Controller / ESC 48V 100A
MFR VoltEdge ControlsMODEL VEC-ESC-48100DEFENCE-ADJACENT
Rugged 48V 100A ESC with smooth throttle response and safety features. Ideal for high-power BLDC drives in UGVs and mobile robots.
We have no supplier for this
VoltEdge Controls makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Specifications· 9 fields
- Weight
- 450 g
- Features
- Regenerative Braking, Thermal/Overcurrent Protection, Soft-Start
- Dimensions
- 120 × 70 × 40 mm
- Peak Current
- 150 A (10 s)
- Input Voltage
- 18–60 V (48 V nominal)
- Operating Temp
- -20 to 85 °C
- Continuous Current
- 100 A
- Control Interfaces
- PWM, CAN, UART
- Switching Frequency
- 8–32 kHz
