Avago AEDR-8300 Optical Encoder
MFR BroadcomMODEL AEDR-8300-102
High-resolution optical rotary encoder for precise position feedback. Features quadrature output and index pulse.
We have no supplier for this
Broadcom makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Specifications· 9 fields
- Weight
- 50 g
- Current
- 40 mA
- Voltage
- 5 V
- Max Speed
- 6000 rpm
- Output Type
- TTL compatible
- Resolution
- 102 CPR
- Operating Temp
- -40°C to +100°C
- Shaft Diameter
- 6 mm
- Quadrature Output
- 408 counts/rev
