Hengstler AC61 Absolute Encoder
MFR Hengstler GmbHMODEL AC61/1213EK.72SPB
High-precision absolute rotary encoder with CANopen interface. Single-turn and multi-turn versions available for precise position feedback in robotics.
We have no supplier for this
Hengstler GmbH makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Specifications· 13 fields
- Cable
- 2m, 5-pin M12 connector
- Shock
- 500g, 1ms
- Supply
- 10-30 VDC
- Current
- 80 mA max
- Accuracy
- ±0.1°
- Max Speed
- 12000 rpm
- Interface
- CANopen
- Vibration
- 55 Hz, 2g
- Flange Size
- 58 mm
- Protection
- IP67
- Resolution
- 13-bit single-turn
- Operating Temp
- -40°C to +100°C
- Shaft Diameter
- 10 mm
