ROBOTIS Dynamixel XM540-W270-T
High-torque smart servo actuator with 8.1Nm stall torque. Features integrated controller, position/velocity/current control modes, and daisy-chain communication for complex robotic systems.
We have no supplier for this
ROBOTIS makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Specifications· 10 fields
- Weight
- 165g
- Feedback
- Magnetic encoder
- Interface
- TTL, RS485
- Dimensions
- Ø54 x 59 mm
- Resolution
- 4096 steps/revolution
- No Load Speed
- 46 RPM at 12V, 61 RPM at 24V
- Stall Torque
- 8.1 Nm at 12V, 10.6 Nm at 24V
- Control Modes
- Position, Velocity, Current
- Protocol Support
- Dynamixel Protocol 2.0
- Operating Voltage
- 12-24V
