Components · Sensors
Bosch BMI088 High-Performance IMU Module
MFR Bosch SensortecMODEL BMI088
Automotive-grade 6-axis IMU with separated gyroscope and accelerometer. Features low noise, high stability, and excellent temperature performance for precise motion tracking.
We have no supplier for this
Bosch Sensortec makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Specifications· 10 fields
- Dof
- 6 (3-axis gyro + accel)
- Gyro Noise
- 0.014 deg/s/√Hz
- Gyro Range
- ±125 to ±2000 deg/s
- Interface
- SPI, I2C
- Accel Noise
- 175 µg/√Hz
- Accel Range
- ±3g to ±24g
- Automotive
- AEC-Q100 qualified
- Dimensions
- 3.0 x 4.5 x 0.95 mm
- Output Rate
- 2 kHz gyro, 1.6 kHz accel
- Operating Voltage
- 2.4-3.6V
