ATI Industrial Automation Axia80 F/T Sensor
MFR ATI Industrial AutomationMODEL Axia80-M20
Precision 6-axis force/torque sensor with 80N force and 20Nm torque capacity. Features silicon strain gauge technology, high resolution, and industry-leading accuracy for assembly and testing.
We have no supplier for this
ATI Industrial Automation makes this, and it is listed here for reference. BOTWERX has no supplier record for it: no vendor, no vendor listing, and no price verified against one. The figure shown is indicative and is not a quote. It is not a shortage — there is no route to it through this catalogue. Ask us and we will tell you whether one can be arranged.
Unit price
$12,995.00
Confirmed before you pay
Priced from live catalog
Seller of record listed
Specifications· 10 fields
- Axes
- 6 (Fx, Fy, Fz, Tx, Ty, Tz)
- Weight
- 1.2 kg
- Accuracy
- 0.25% of full scale
- Mounting
- M20 x 1.5 thread
- Interface
- Ethernet, EtherCAT, DeviceNet
- Force Range
- ±80N (Fx, Fy), ±240N (Fz)
- Resolution
- 1/80 N, 1/800 Nm
- Sample Rate
- 7000 Hz
- Torque Range
- ±20Nm
- Overload Capacity
- 300% in all axes
